Double Strand Corrosion Resistant Chain

Bearing Pin Diameter

3.28 mm

Width over joint Fasteners

27.1 mm

Width Over Bearing Pin

23.8 mm

Width Between Inner Plates

5.72 mm

Tensile Strength

Strong

Roller Diameter (mm)

10-20

Roller Diameter

6.35 mm

Plate Height

8.2 mm

Material

Stainless Steel

Length of Chain

10 mm

Color

Black

Chain Width (mm)

5 mm

Intl Ref no.

Diamond Chain No.

Pitch (P)

Width between
Inner Plates (W) MIN

Roller
Dia
(D)
MAX

Plate
Height
(H)
Max

Bearing Pin Dia
(d)
MAX

Width over bearing Pin (A) MAX

Width over joint Fasteners
(B) MAX

Transverse Pitch (P1)

Projected bearing Area
(sq.cm)

Avg Weight per metre (Kg)

Tensile
Strength
(Kgf) MIN

06B-1

D06102SS01

9.525

5.72

6.35

8.2

3.28

23.8

27.1

10.24

0.56

0.74

1000

08B-2

D08302SS01

12.7

7.75

8.51

11.8

4.45

31

34.9

13.92

1

1.4

2160

10B-2

D10102SS01

15.875

9.65

10.16

14.7

5.08

36.2

40.3

16.59

1.34

3

2900

12B-2

D2002SS01

19.05

11.68

1207

16.1

5.72

42.2

46.8

19.46

1.76

2.21

3800

16B-2

D16002SS01

25.4

17.02

1588

21

8.27

68

73.4

31.88

4.14

5.08

7590
